Description
Technical Specifications
- Model: CNCC120W36.
- Maximum Power at STC (Pmax): 120 W.
- Optimum Operating Voltage (Vmp): 18.2 V.
- Optimum Operating Current (Imp): 6.594 A.
- Open-Circuit Voltage (Voc): 21.84 V.
- Short-Circuit Current (Isc): 7.056 A.
- Solar Module Efficiency (%): 14.96.
- Dimensions: 1180 mm * 680 mm * 30 mm.
- Weight: 11kg
- Front: glass 3.2mm tempered glass.
- Frame: Anodized aluminum alloy.
- Operating Temperature: -40°C to 85°C
- Maximum System Voltage: 1000 VDC.
STC: Irradiance 1000W/㎡, Modules Temperature 25℃, AM=1.5
